Chaservo
Weight: 81g
Dimensions: 40.5 x 20 x 40 mm
Rated Voltage: DC 7.4V
Voltage Range: DC 4.8 – 8.4V
Output Shaft Spline: 25T, 0.236 in (6 mm)
Holding Torque @ 4.8V: 13.5 kg·cm
Holding Torque @ 6.0V: 16.5 kg·cm
Holding Torque @ 7.4V: 20 kg·cm
Holding Torque @ 8.4V: 22.5 kg·cm
Output Torque @ 4.8V: 9 kg·cm
Output Torque @ 6.0V: 11 kg·cm
Output Torque @ 7.4V: 13.5 kg·cm
Output Torque @ 8.4V: 15 kg·cm
No-load Speed @ 4.8V: 0.090sec/60°
No-load Speed @ 6.0V: 0.070sec/60°
No-load Speed @ 7.4V: 0.055sec/60°
No-load Speed @ 8.4V: 0.050sec/60°
max. Current @ 6.0V: 4.55 A
max. Current @ 7.4V: 5.12 A
max. Current @ 8.4V: 6.15 A
Case Material: Aluminium
Gear Set Material: Metallgetriebe
Ball Bearing: 2 x Ball Bearing
Position sensor: Potentiometer
Motor: Coreless DC
Working Frequency: 1520µs/333Hz
Pulse Range: 500 μs – 2500 μs
Programmable: Yes
